DIN 2527 PN6 Blind Flange Dimensions
| Nominal Pipe Size | Flange Dimension | Screw Parameter | Approx. Flange Weight |
| Flanges Dia | Thk of Flange | Dia of Bolt Circle | No. of holes | Dia of Bolt Holes |
| DIN | D | b | k | X | d2 | KG/PCS |
| 10 | 75 | 12 | 50 | 4 | 11 | 0.38 |
| 15 | 80 | 12 | 55 | 4 | 11 | 0.44 |
| 20 | 90 | 14 | 65 | 4 | 11 | 0.66 |
| 25 | 100 | 14 | 75 | 4 | 11 | 0.82 |
| 32 | 120 | 14 | 90 | 4 | 14 | 1.18 |
| 40 | 130 | 14 | 100 | 4 | 14 | 1.39 |
| 50 | 140 | 14 | 110 | 4 | 14 | 1.62 |
| 65 | 160 | 14 | 130 | 4 | 14 | 2.14 |
| 80 | 190 | 16 | 150 | 4 | 48 | 3.43 |
| 100 | 210 | 16 | 170 | 4 | 18 | 4.22 |
| 125 | 240 | 18 | 200 | 8 | 18 | 6.1 |
| 150 | 265 | 18 | 225 | 8 | 18 | 7.51 |
| 175 | 295 | 20 | 255 | 8 | 18 | 10.41 |
| 200 | 320 | 20 | 280 | 8 | 18 | 12.31 |
| 250 | 375 | 22 | 335 | 12 | 18 | 18.55 |
| 300 | 440 | 22 | 395 | 12 | 22 | 25.47 |
| 350 | 490 | 22 | 445 | 12 | 22 | 31.78 |
| 400 | 540 | 22 | 495 | 16 | 22 | 38.5 |
| 500 | 645 | 24 | 600 | 20 | 22 | 60.13 |
| 600 | 755 | 28 | 705 | 20 | 26 | 96.07 |
| 700 | 860 | 30 | 810 | 24 | 26 | 133.8 |
| 800 | 975 | 32 | 920 | 24 | 30 | 183.29 |
| 900 | 1075 | 36 | 1020 | 24 | 30 | 251.7 |
| 1000 | 1175 | 42 | 1120 | 28 | 30 | 350.98 |
