A complex piping network encompasses pipes of varied sizes, which may also be designed in a manner that these pipes may require frequent changes. Consequently, the pipe’s diameter undergoes regular changes to adjust to the incoming stream of variations. Here is where a Stainless Steel Reducing Flange enters: be it in Monel, Inconel, Hastelloy, Carbon Steel or Alloy Steel, it possesses the ability to join pipes of varied sizes together with great ease. ANSI B16.5 Alloy Steel Reducing flanges can endure extreme pressure and are suitable for high-pressure systems like condensers and boilers.
| Material Category | Available Grades |
|---|---|
| Stainless Steel Flanges | ASTM A182 / A240 F304, F304L, F304H, F316, F316L, F316Ti, F310, F310S, F321, F321H, F317, F347, F347H, F904L. |
| Duplex & Super Duplex Steel Flanges | ASTM/ASME A/SA 182 F44, F45, F51, F53, F55, F60, F61. |
| Carbon Steel Flanges | ASTM/ASME A/SA 105, ASTM/ASME A350, ASTM A181 LF2, ASTM A516 Gr.70, ASTM A36, ASTM A694 F42, F46, F52, F60, F65, F70. |
| Low Temperature Carbon Steel Flanges | ASTM A350 LF2, LF3. |
| Alloy Steel Flanges | ASTM/ASME A/SA 182 & A387 F1, F5, F9, F11, F12, F22, F91. |
| Copper Alloy Flanges | ASTM SB61, SB62, SB151, SB152, UNS C70600 (Cu-Ni 90/10), C71500 (Cu-Ni 70/30), C10100, C10200, C10300, C10800, C12000, C12200. |
| Nickel Alloy Flanges | ASTM SB564, SB160, SB472, SB162, Nickel 200 (UNS N02200), Nickel 201 (UNS N02201), Monel 400 (UNS N04400), Monel K500 (UNS N05500), Inconel 800 (UNS N08800), Inconel 825 (UNS N08825), Inconel 600 (UNS N06600), Inconel 625 (UNS N06625), Inconel 601 (UNS N06601), Hastelloy C276 (UNS N10276), Alloy 20 (UNS N08020). |
Our Reducing and Expanding Flanges are used for connecting different pipeline diameters while maintaining pressure integrity in process lines. We supply project and replacement requirements with controlled quality, dimensional checks, and material traceability as per ASME B16.5 / ANSI.
Industries Served: oil & gas, petrochemical, power, EPC, shipbuilding, water treatment, process manufacturing, and heavy engineering.
Supply Regions: India, GCC/Gulf countries, and global export destinations with commercial support for manufacturer, supplier, stockist, and exporter requirements.
Explore More: Flanges | Forged Fittings | Buttweld Fittings | Olets
Certified stainless steel billets are selected according to ASTM, ASME, and EN standards.
Billets are heated and forged into the required flange shape for maximum strength.
Precision machining creates the bore, facing, bolt holes, and required dimensions.
Stress relieving and solution annealing are performed whenever required.
PMI, dimensional inspection, hydrostatic testing, and NDT ensure product quality.
Flanges are cleaned, pickled, passivated, and finished as per customer requirements.
Each flange receives grade, size, heat number, and standard identification markings.
Products are packed securely with flange protectors, wooden pallets, and export-ready crates.
When is it appropriate to use a Reducing Flange instead of a Buttweld Reducer?
A Reducing Flange is a cost-effective solution when transitioning from a larger pipe to a smaller pipe, such as from a 4-inch line to a 2-inch valve, especially where installation space is limited. It combines the flange and reducing function into a single component, provided the application does not involve excessive turbulence or flow restrictions.
Can Reducing Flanges be used as Blind Flanges?
Not exactly. Although a Reducing Flange is structurally similar to a Blind Flange, it includes a central threaded or weldable bore that connects the smaller branch pipe, whereas a Blind Flange has no center opening and is used to completely seal the pipeline.
